3D Printing
3D Printing
3D printing refers to a variety of processes which can construct a part of nearly any geometry by depositing raw material one layer at a time. At LST, 3D printing is designed for functional prototypes, complex designs, and production components as fast as 1 day. We can offer SLA, SLS, Metal printing, Multi Jet Fusion (MJF) services.
3D Printing capabilities
| SLA | SLS | DMP | |
|---|---|---|---|
| Maximum build size | 800*800*550 mm | 400*400*450mm | 280*280*350 |
| Dimensional accuracy | L < 100 mm: ±0.15 mm L≥100 mm: ±0.15% * L |
L < 100 mm: ±0.20 mm L≥100 mm: ±0.20% * L |
L < 100 mm: ±0.25 mm L≥100 mm: ±0.25% * L |
| Minimum feature size | 0.3 mm | 0.4 mm | 0.5 mm |
| Material | Resin | PA, PA+GF |
TC4, AlSi10Mg, 316L, 1.2709 |
|
Available Surface effect |
Polishing, Paint spraying | Polishing, Paint spraying | Polishing, Machining |
| Standard lead time | 3 days | 6 days | 10 days |
